Artificial Lift Solutions
Jet Pumps Technology
Apex offers a broad range of highly engineered artificial lift equipment, package solutions, and services, including jet pumping technology, power units, downhole accessories, and automation and monitoring technologies. Services include commissioning, maintenance, and operations.
Apex offers a broad range of highly engineered artificial lift equipment, package solutions, and services, including jet pumping technology, power units, downhole accessories, and automation and monitoring technologies. Services include commissioning, maintenance, and operations.
To suit changing production requirements and downhole conditions, the nozzle, mixing tube, and diffuser can be assembled using a variety of materials in multiple configurations:
Specifications
Scroll horizontally to view the complete table
| Parameter | Typical Range | Maximum |
|---|---|---|
| Operating Depth | 5,000 to 10,000 ft | 20,000 ft |
| Operating Temperature | 100° to 250°F | 500°F |
| Wellbore Deviation | 0° to 20° | 0° to 90° |
| Operating Volume | 300 to 1,000 B/D | ≤35,000 B/D |
Scroll horizontally to view the complete table
| Tubing Size (in.) | Pump Type | Maximum Production Rate (B/D) |
|---|---|---|
| 1 ½ | Standard | 400 |
| 1 ½ | High volume | 600 |
| 2 | Standard | 2,000 |
| 2 | High volume | 2,500 |
| 2 ½ | Standard | 3,000 |
| 2 ½ | High volume | 3,500 |
| 3 | Standard | 4,000 |
| 3 | High volume | 4,500 |
